Weight | 11.5g |
Dimensions | 54x16x12mm plus ~50mm external whip antenna Length includes 4mm depth sensor |
Battery-only Capacity | ~5000 GPS location attempts including regular UHF download attempts, but with no depth data. See Table D for illustrations of the impact depth data transmission would have on the battery capacity of this tag (excluding solar) |
Solar Capacity | ~240 GPS location attempts per day in UK summertime conditions. The daily volume of depth data to be wirelessly transmitted will impact this capacity - please contact us for more details |
Onboard storage | 40000 GPS location attempts Remaining memory reserved for depth data |
Immersion Sensor | Onboard sensor used to avoid wasted power when bird is submerged |
UHF Download Range | Up to 2km in ideal conditions, 100-200m in typical conditions |
Depth Sensor | Depth and temperature sensor rated to 290m Configurable sample rate and depth threshold |
Programming Interface | Wireless configuration via base station |
Waterproofing | Depth proof to 100m |
Packaging | Duraform housing and epoxy |
Attachment Method | Tape or glue |
Pathtrack tags have been deployed on a wide variety of species around the world. Browse our different categories to see if you can find the species that you are looking to study.
